Phillips Head Wood Screws in Brass – Manufacturer, Supplier & Exporter | Conex India
Conex Screws and Fasteners is a premier manufacturer and exporter of Brass Phillips Head Wood Screws (also known as Brass Cross Head Wood Screws or Brass Phillips Drive Wood Screws) from Jamnagar, India. With over 30 years of precision fastener manufacturing experience, we supply brass Phillips wood screws to customers in the USA, UK, Australia, Canada, Germany, the Middle East, and 50+ countries worldwide. Our brass Phillips head wood screws are prized for their golden aesthetic appearance, excellent corrosion resistance, non-magnetic properties, and compatibility with Phillips No. 2 screwdrivers available worldwide.
What Are Brass Phillips Head Wood Screws?
Brass Phillips Head Wood Screws are self-tapping timber fasteners with a cross-shaped (Phillips) recess on the head, designed to be driven by a Phillips No. 2 screwdriver or bit. They combine the beautiful golden appearance and corrosion resistance of brass with the ubiquitous availability of Phillips drive tooling worldwide. Available in countersunk (flat), raised countersunk, and round head styles, they are ideal for decorative joinery, cabinetry, furniture assembly, musical instrument construction, electrical enclosures, and any application where appearance and corrosion resistance are equally important.
Why Choose Phillips Drive for Brass Wood Screws?
The Phillips drive (cross recess) is the most universally available screwdriver type worldwide, making Phillips head brass wood screws the practical choice for installers in the field, production assembly lines, and DIY applications. The cross-recess allows higher torque transmission than slotted drive, reducing cam-out and driver slippage, and is compatible with both manual screwdrivers and power tools fitted with PH2 bits.
Material Grades & International Equivalents
| Standard | Grade | Composition | Region |
|---|---|---|---|
| IS | 319 Type 1 | CuZn39Pb3 (Free Machining Brass) | India |
| ASTM | C36000 | 60% Cu, 38% Zn, 2% Pb | USA |
| EN | CW614N | CuZn39Pb3 | Europe |
| DIN | 2.0401 | CuZn39Pb2 | Germany |
| BS | CZ121 | Free Machining Brass | UK |
| JIS | C3604 | Free cutting brass | Japan |
| UNS | C36000 | Free machining brass rod | USA |
Head Styles Available
| Head Style | Drive | Standard | Best Use |
|---|---|---|---|
| Countersunk (CSK / Flat Head) | Phillips PH2 | DIN 7997 / ISO 7046 | Flush fitting, cabinetry, joinery |
| Round Head | Phillips PH2 | DIN 7996 / ISO 7048 | Decorative, light joinery, crafts |
| Raised Countersunk (Oval) | Phillips PH2 | DIN 7995 | Semi-decorative flush fitting |
| Pan Head | Phillips PH2 | DIN 7981 | General purpose assembly |
Size & Dimensional Chart – Metric (mm)
| Size | Thread Type | Head Dia CSK (mm) | Head Dia Round (mm) | Length Range (mm) |
|---|---|---|---|---|
| M3 | Coarse | 6.0 | 5.6 | 10–40 |
| M4 | Coarse | 8.0 | 7.5 | 12–60 |
| M5 | Coarse | 10.0 | 9.5 | 16–80 |
| M6 | Coarse | 12.0 | 11.5 | 20–100 |
| M8 | Coarse | 16.0 | 15.5 | 25–120 |
Size & Dimensional Chart – Gauge / Imperial
| Gauge | Shank Dia (in) | TPI | Head Dia CSK (in) | Length Range (in) |
|---|---|---|---|---|
| #4 | 0.112 | 20 | 0.225 | 3/8”–1” |
| #6 | 0.138 | 18 | 0.270 | 1/2”–2” |
| #8 | 0.164 | 15 | 0.322 | 5/8”–3” |
| #10 | 0.190 | 13 | 0.373 | 3/4”–3” |
| #12 | 0.216 | 11 | 0.425 | 1”–4” |
Key Features & Performance Metrics
- Drive Type: Phillips No. 2 (PH2) – universally compatible with all standard Phillips screwdrivers and power tool bits
- Material: CZ121 / C36000 Free Machining Brass (standard); Naval Brass or low-lead alternatives on request
- Tensile Strength: 350–450 MPa
- Hardness: 60–80 HRB
- Corrosion Resistance: Excellent in atmospheric, freshwater, and mild chemical environments
- Non-Magnetic: Safe for electrical panels, instrument making, and sensitive electronic environments
- Non-Sparking: Suitable for use in potentially explosive or flammable environments
- Appearance: Natural golden brass finish – aesthetically superior to zinc-plated or stainless steel for decorative joinery
- Surface Finish Options: Natural brass, bright nickel plated, tin plated, chrome plated
Applications
Brass Phillips head wood screws are used in decorative furniture and cabinetry, musical instrument construction (guitars, violins, pianos), wooden jewellery and display boxes, boat interior joinery and cabin fittings, picture frames and art installations, wooden window frames and sash hardware, antique restoration, electrical distribution boards with wooden backing plates, wooden instrument panels, and luxury retail fixture and display units where appearance matters.
Why Choose Conex Over Other Manufacturers?
- 30+ Years of Experience: Three decades of brass fastener manufacturing from Jamnagar – the global capital of brass components
- Faster Turnaround: Standard sizes dispatched within 7–14 working days; urgent orders accommodated
- Superior Customer Support: Dedicated account managers, responsive across all time zones
- Excellent Communication: English-fluent technical team with prompt RFQ responses and proactive shipment updates
- Global Exposure: Active exporters to 50+ countries – USA, UK, Australia, Germany, Canada, UAE and beyond
- Competitive Pricing: Direct manufacturer pricing with no middlemen
- Quality Assurance: ISO-certified manufacturing; MTC, dimensional reports, and compliance certificates provided
- Custom Capability: Non-standard sizes, special finishes, private labelling, custom packaging
Our Flexibility to Customise
We manufacture brass Phillips head wood screws in custom lengths, special diameters, Metric Fine and BSW/BSF thread forms, special head styles, and with surface treatments including bright nickel, tin, silver, and chrome plating. Custom engraving, special packaging, and private labelling are available. Both small sample and large production orders are accommodated.
What Separates Conex from Other Manufacturers
Jamnagar is home to the world’s largest brass component manufacturing cluster, and Conex has been a direct exporter from this region for over three decades. Our in-house cold forging, thread rolling, and head-slotting/recessing operations ensure consistent dimensional accuracy and Phillips recess depth critical for proper driver engagement. We provide complete export documentation including material test certificates, RoHS declarations, and origin certificates as standard.
Export-Worthy Packaging
- Inner: Polybags sorted by size, head type, and finish
- Outer: Double-wall corrugated export cartons
- Labelling: Grade, head style, drive, size, finish, quantity, batch, country of origin on every carton
- Moisture protection: Desiccant packs for sea freight and humid climate shipments
- Palletisation: ISPM-15 compliant heat-treated wooden pallets for FCL shipments
Technical Q&A – Phillips Head Brass Wood Screws
Q1. What is the Phillips drive recess size for brass wood screws?
A: The vast majority of brass wood screws use Phillips No. 2 (PH2) recess. For smaller sizes (#4 metric M3 and below), Phillips No. 1 (PH1) may be used. We specify the drive size clearly on all order documentation.
Q2. What is the difference between Phillips and Pozi drive?
A: Phillips (cross recess) has tapered flanks designed to cam-out under excessive torque, reducing screw damage. Pozi (Pozidrive) has additional ribs between the four arms and straighter flanks for better torque transmission without cam-out. We can supply brass wood screws with either Phillips or Pozi drive on request.
Q3. What brass grade is used for Phillips head wood screws?
A: Standard is CZ121 / C36000 Free Machining Brass (CuZn39Pb3). For RoHS-compliant or food-grade applications, low-lead brass (C35300) or lead-free brass (C69300 ECO Brass) alternatives are available.
Q4. What standards do brass Phillips head wood screws conform to?
A: Brass CSK Phillips wood screws conform to DIN 7997 / ISO 7046. Round head Phillips wood screws conform to DIN 7996 / ISO 7048. Raised countersunk types conform to DIN 7995. Material conforms to BS CZ121 / ASTM C36000.
Q5. Are brass Phillips wood screws non-magnetic?
A: Yes – brass is inherently non-magnetic, making brass Phillips head wood screws suitable for electrical panels, instrument making, marine electronic equipment mounting, and any application where magnetic interference must be avoided.
Q6. Can brass wood screws be used in outdoor applications?
A: Brass offers excellent resistance to atmospheric corrosion and mild chemical environments. For general outdoor use (garden furniture, window frames, planters), brass Phillips wood screws perform well. For coastal or marine environments, Grade 316 stainless steel or silicon bronze is recommended.
Q7. Do you supply brass wood screws with nickel plating?
A: Yes. Bright nickel plated brass Phillips wood screws are available in all standard sizes. Nickel plating enhances corrosion resistance and provides a silver-coloured finish that complements modern furniture and hardware designs.
Q8. What is the minimum order quantity for brass Phillips wood screws?
A: We supply from as low as 100 pieces for samples. Standard production orders start from 1,000 pieces per size. FCL quantities available for large requirements.
Q9. Are brass Phillips wood screws RoHS compliant?
A: Standard CZ121 brass contains lead and is not fully RoHS compliant. Lead-free ECO Brass (C69300) alternatives are available for RoHS-compliant applications – please specify when enquiring.
Q10. Can you supply brass wood screws in BSW thread?
A: Yes – we supply brass Phillips head wood screws in BSW, BSF, UNC, UNF, and Metric thread forms to meet UK, American, and international customer requirements.
Q11. What head styles are available with Phillips drive?
A: Countersunk (flat/CSK), round head, raised countersunk (oval), and pan head – all with Phillips No. 2 drive as standard.
Q12. Can brass wood screws be chrome plated?
A: Yes – chrome plated brass Phillips wood screws are available for high-end decorative applications in furniture, automotive, and luxury retail fixtures.
Q13. What is the lead time for brass Phillips wood screws?
A: Standard sizes: 7–14 working days from Jamnagar. Custom dimensions or special finishes: 3–4 weeks. Urgent requirements can be prioritised.
Q14. Do you provide material test certificates?
A: Yes – MTCs with chemical composition data for all export orders. Dimensional inspection reports available on request.
Q15. Are brass Phillips wood screws suitable for musical instruments?
A: Yes – brass Phillips head wood screws are widely used in guitar construction, piano action assembly, violin and viola chin rest fittings, and other musical instrument hardware where non-magnetic, corrosion-resistant, aesthetically pleasing fasteners are required.
Customer Testimonials
Mark Henderson, Custom Furniture Designer – London, UK
“Conex has been supplying our workshop with brass Phillips head wood screws for bespoke cabinet and furniture projects for years. The quality is consistently excellent, the brass finish is beautiful, and delivery is always reliable. Our clients appreciate the premium look that brass screws give to our pieces.”
James Kowalski, Marine Interior Contractor – Florida, USA
“We use Conex brass Phillips screws extensively for yacht and boat interior joinery. The quality is superb – consistent dimensions, clean Phillips recess, and a beautiful golden finish that looks great in teak and mahogany interiors. Competitive pricing and excellent customer service.”
Glossary of Related Terms
Phillips Drive (PH2): Cross-recess screw drive invented by Henry Phillips; the most common screwdriver type worldwide | Countersunk (CSK): Flat-headed screw that sits flush with the surface when fully driven | CZ121: British Standard designation for free machining brass (CuZn39Pb3) | C36000: ASTM/UNS designation for free machining brass | DIN 7997: German standard for cross-recessed countersunk wood screws | ISO 7046: International standard for Phillips CSK wood screws | Non-Magnetic: Property of brass preventing magnetic interference | Free Machining Brass: Brass alloy with lead for improved machinability | Cam-Out: Slippage of Phillips driver out of screw recess when torque is exceeded | Pozi (Pozidrive): Enhanced cross recess drive with additional ribs for better torque transfer
