Copper Clamps, Copper Pipe Clamps, Copper Conduit Pipe Clamps
Copper Clamps, Copper Pipe Clamps, Copper Conduit Pipe Clamps
Price: US$ 10.90/kilogram
We are one of the leading manufacturers and exporters of Copper Clamps and Copper Pipe Clamps from India. We have been supplying high-quality Copper fastening , Copper pipe support system, Copper saddles, Pipe saddles, and Copper pressed clamps and pipe support solutions to the world market for many decades. Our Copper Clamps are precision-engineered components used widely in electrical, plumbing, and industrial applications, offering excellent conductivity, corrosion resistance, and structural reliability. These clamps are suitable for both commercial and industrial use and are designed for long life and performance. With in-house casting, stamping, CNC machining, and finishing facilities, we deliver customized Copper Conduit Pipe Clamps with quick turnaround times and adherence to international standards. We also offer customer-brand packaging and labelling solutions tailored for global markets. Our experience in metal processing, consistent quality, and excellent communication make us a trusted global supplier.
Copper Clamps These are general-purpose support brackets made from high-conductivity Copper, typically used to fasten pipes, wires, or tubes to walls or panels. Made from grades like C11000 (ETP Copper) or C12200 (DHP Copper), they are manufactured using stamping, pressing, and punching operations. Typical thickness ranges from 0.8 mm to 2.0 mm. Finishes include Mill Finish, Electropolished, or Tin-Plated on request.
Copper Pipe Clamps These are heavy-duty clamping assemblies designed for round pipes. Manufactured from C11000 or C12200 Copper, these clamps are machined and pressed for dimensional accuracy and mechanical strength. They include fastening screws (Brass or Stainless Steel) and are used in HVAC, plumbing, and fire protection systems. Typical sizes range from 10 mm to 100 mm diameter. Our CNC stamping and hydraulic forming ensure precise tolerances of up to ±0.1 mm.
Copper Conduit Pipe Clamps These are specialized clamps used in electrical conduit installations, especially where high grounding efficiency is required. Made from ETP Copper, they are fabricated with smooth edges and burr-free finishes to avoid insulation damage. They meet ASTM B152 and BS EN 1976 standards. Sizes range from 12 mm to 75 mm. Finishes can include Nickel Plating or Electro Tin Coating.
Copper Saddles Copper Saddles are lightweight, one-piece brackets designed to secure small diameter pipes, tubes, or cables to walls, panels, or floors. They are especially useful in neat installations of Copper or PVC conduits where minimal profile and strong hold are desired. Manufactured using high-quality C11000 Copper, these saddles are stamped from Copper strips and then deburred for safety and precision. Standard sizes range from 6 mm to 38 mm and meet installation needs in electrical, plumbing, and telecom sectors. Copper Saddles are known for their simple installation, corrosion resistance, and excellent aesthetic compatibility in exposed runs.
Manufacturing Process
- Material Procurement: ETP/DHP Copper Sheets or Strips
- Cutting and Blanking
- Power Press Forming
- CNC Machining (as required)
- Deburring and Polishing
- Surface Treatment
- QC and Dimensional Verification
Machinery Used
- Hydraulic Presses (10-60 Ton)
- Power Press Machines
- CNC Turning Centers
- Vibratory Deburring Machines
- Electroplating & Coating Units
Material Property Table
| Property | C11000 Copper (ETP) | C12200 Copper (DHP) |
|---|---|---|
| Electrical Conductivity | 100% IACS | 85% IACS |
| Tensile Strength | 210 MPa | 250 MPa |
| Elongation | 30% | 35% |
| Corrosion Resistance | Excellent | Excellent |
Packaging and Shipping We offer customized packaging including poly bags, blister packs, or bulk packaging in corrugated boxes with customer logo and barcode labelling. Shipping is via air, sea, or express courier as per client preference.
Industries Using Copper Clamps
- Electrical Panel and Cable Support Systems
- Plumbing and HVAC Installations
- Fire Protection Lines
- Grounding and Lightning Protection Systems
- Marine and Shipbuilding Industry
Turnaround Time Standard production time: 4-6 weeks depending on order size and customization requirements.
Size-Dimensional Chart
| Clamp Type | Pipe OD (mm) | Clamp Width (mm) | Hole Dia (mm) | Thickness (mm) |
| Copper Strap Clamp | 12 – 75 | 14 – 25 | 5 – 8 | 1.0 – 2.0 |
| Copper Pipe Clamp | 10 – 100 | 20 – 35 | 6 – 10 | 1.5 – 3.0 |
| Copper Conduit Clamp | 12 – 63 | 16 – 30 | 6 | 1.2 – 2.5 |
Performance Metrics
- Max Operating Temp: 150°C
- Torque Tolerance: Up to 15 Nm (for bolted types)
- Life Expectancy: Over 15 years in standard environments
Why Choose Us?
- Over 30 Years of Global Export Experience
- Fast Response and Engineering Support
- Customization with Small Batch Flexibility
- In-house Tooling and Design
- Flexible Delivery Schedules
- Dedicated Account Managers
Typical Questions and Answers
- Can you customize the size or hole position?
- Yes, based on drawings or samples.
- Do you offer RoHS-compliant finishes?
- Absolutely, upon request.
- Can you provide certifications?
- Yes, material test certificates and dimensional reports.
- Are your products UL or CE marked?
- UL approval can be arranged for large-volume orders.
- What’s the MOQ?
- We cater to both small and large orders; MOQ is flexible.
- Do you offer OEM services?
- Yes, with logo stamping and packaging.
- How are returns handled?
- We offer replacements or refunds for proven defects.
- Do you support scheduled deliveries?
- Yes, including blanket orders.
- What is your payment term?
- Standard is 30% advance, balance before dispatch.
- Can you do barcoding and customer label printing?
- Yes, as per specifications.
Customer Testimonial “We’ve worked with Conex India for over 5 years. Their Copper Clamps are top-notch in finish and quality. Prompt communication and delivery make them stand out. Highly recommended!” — Mike Harper, California, USA
Glossary of Terms
- ETP Copper: Electrolytic Tough Pitch Copper with 99.9% purity.
- DHP Copper: Deoxidized High Phosphorus Copper, good for brazing.
- IACS: International Annealed Copper Standard for conductivity.
- OD: Outer Diameter.
- MOQ: Minimum Order Quantity.
Related Search Terms Copper saddle clamps, copper U clamps, copper pipe support bracket, copper tube strap, copper pipe fixing clamp, electrical conduit copper clamps , Copper inserts, Copper pressed components
Contact us today for a quote, email us for a brochure, or connect via WhatsApp to discuss your custom Copper Clamp requirements!
